We are able to supply high quality framed laser cut solder paste stencils made to the client's specifications at very competitive prices.

We have a vast amount of experience in this field,who have been in this business for over 10 years.

Our laser cut Stencils provide optimum solder paste volume control. They have smooth aperture walls and can be used for fine pitch components as well as Micro BGAs.

Electroformed and laser cut electro-polished stencils produce the best printing characteristics among stencil types. Stencil aperture design is a crucial step in optimizing the print process.

TECHNOLOGY CAPABILITIES

Framed SMT Stencils are 100% laser cut
Material used: Electro-polished stainless steel
Standard stencil thickness: 0.15mm (0.006") - Other thicknesses available on request
Minimum cut width: 0.05mm (0.002 inches)
Typical Frame size: 650 x 750 mm (25" x 29")
We make all aperture modifications necessary
Aperture tolerance: +/-9um (0.0003")
Allowance for fiducial data
Allowance for panelized data
Suitable applications: All component pitches down to 0.4mm (0.016”) and all discrete components down to 0201’s
